The MiR600 is a stronger and safer AMR. The MiR600 is compliant with the highest available robot standards making it superior to other AMRs on the market. With increased ability to withstand dust particles and fluids along with being compliant to the highest safety standards on the market, the MiR600 is safer, more stable and more reliable than other AMRs on the market.
Quick Facts about the MiR600
Safe and efficient maneuvering
The collaborative MiR600 safely maneuvers around people and physical obstacles. With its advanced technology and sophisticated software, the robot autonomously navigates to find the most efficient path to its destination. When it meets obstacles, it will automatically re-route to avoid costly lags in logistics processes.
MiR600 is equipped with the latest laser-scanning technology that delivers a 360-degree visual for optimal safety. 3D cameras have a range of 30-1,800 mm above floor level to detect pallets.
Optimize pallet transportation without changing facility layout
With the MiR600 Pallet Lift, the MiR600 picks up, transports and unloads pallets autonomously, freeing up employees for more valuable tasks. There is no need to change the facility layout when operating the MiR600 as the function of wires, magnets or QR codes is replaced by sophisticated navigation software. Simply download CAD files of the facility to the robot or use its laser scanners to create a map - that’s all it takes to ensure a fast and cost-efficient implementation.
A robust robot for the industry
The MiR600 is the first IP52 rated AMR on the market together with MiRs other heavy duty robots, the very powerful MiR1350. With increased ability to withstand dust particles and fluids the mobile robot can be used in more environments, it can e.g. drive close to open gates or other places where it is exposed to waterdrops and dirt.
Highly user friendly and flexible
The user-friendly MiR600 gives you full control of the robot from the very start. MiR600 is controlled with the intuitive MiR Robot Interface via smartphone, tablet or PC, and can be programmed without any prior experience. The robot can also be integrated into your ERP system for a fully automated solution.
With the ability to quickly and easily integrate different top modules, the MiR600 can be equipped with pallet forks, conveyors, a robot arm or other options to support a wide range of applications.
Autonomous mobile robot (AMR) for internal transportation of heavy loads and pallets
RAL 7011 / Iron Gray
Specifications may vary based on local conditions and application setup
1 350 mm | 53.1 in
910 mm | 35.8 in
322 mm | 12.7 in
243 kg | 536 lbs
27 mm | 1.0 in
1 304 × 864 mm | 51.3 × 34 in
600 kg | 1 322.8 lbs
2.0 m/s (7.2 km/h) | 6.6 ft/s (4.4 mph)
|Operational corridor width for two robots passing||
With default setup: 4 250 mm | 167.3 in
With minimized footprint and muted Protective fields: 2 700 mm | in 106.3 in
|Positioning accuracy (in controlled conditions)||
Docking to VL-marker: ± 2 mm | 0.08 in on X-axis, ± 3 mm | 0.12 in on Y-axis, ± 0.25° yaw
|Traversable gap tolerance||
Less than 30 mm | 1.18 in
|Active operation time with maximum payload||
up to 8 h 30 min
|Active operation time with no payload||
Up to 11 h
|Standby time (robot is on and idle)||
Up to 16 h
Li-NMC, 47.7 V, 34.2 Ah
Up to 1:12 (10 min charging gives 2 h runtime with maximum payload)
Up to 35 A
|Number of full charging cycles||Minimum 3 000 cycles|
For indoor use only
|Ambient temperature range, operation||
5–40°C | 41–104°F (the maximum ambient temperature only apply up to 1 h)
No water, no oil, no dirt
|Designed to meet safety standards for industrial vehicles||
ISO 13849-1, ISO 3691-4 (except Clause 4.4, 4.9.4, 5.1, 5.2, 6, and Annex A), ISO 12100, ISO 13850
13 safety functions according to ISO 13849-1, certified by TüV Rheinland. The robot stops if a safety function is triggered.
2.4 GHz 802.11 g/n, 5 GHz 802.11 a/n/ac
4 digital inputs, 4 digital outputs, 1 Ethernet port with Modbus protocol
|SICK safety laser scanners||
2 pcs, microScan3 (front and rear), give 360° visual protection around the robot
2 pcs, 3D camera Intel RealSense™ D435
|Signal and status lights||
Indicator lights on four sides, eight signal lights (two on each corner)
